FEATURES:
Direct readout of gas flow rates at any temperature and pressure ove 12 industry standard flow rates: 1, 10, 20, 30, 50, 100, 200, 300, 500 (SCCM); 1, 2, 3, 5 (SLM). ALL IN ONE UNIT !!!
Compatible with most mass flow controllers.
Units may be linked to control proportional and ratio via computer or by daisy chaining units with one acting as a master and subsequent units acting as slaves.
Remote computer control or local control of flow rates.
Valve override switches and indicator for positive shutoff of process gas.
Output short circuit protection.
Front panel zero trim.
Front panel adjustment for flow rate, temperature and gas factor, and zero adjustment compensation.
Fits four across in an standard 19" rack via a rack adaptor and is fully enclosed for table top applications.
Twenty turn potentiometers for set point, gas factor, and zero trim for the most precise settings.
Three and one-half digit display indicates precise flow rate plus or minus one digit, with repeatability to a single digit.
All flow ranges are selected from the rear panel.
Internal or external 5V reference selection.
Durable fully enclosed and shielded enclosure with a mark resistant finish for industrial applications.
Adapter cables available for mass flow controllers.
High accuracy, 1% of full scale.
